Power Meters Reflective Indicator HTN LCD
This HTN LCD display is used in medical sphygmomanometers, in financial electronic POS machines, thermometers in instrumentation, voltage controller panels, electronic products such as electronic calendars.
The display parameters in the table below refer to the dimensions of the figure below. If you have other requirements, you can tell us the parameters such as size, or tell us the products you need to adapt. We can provide you with the right model for you to choose.
General Specification
|
P/N |
SDH-13304-HP-4 |
|
Power Supply |
3.0V |
|
Display Type |
HTN, POSITIVE ,TRANSFLECTIVE |
|
Viewing Direction |
12.00 O’clock |
|
LCD Driving Method |
1/4 Duty, 1/3 Bias, 3.0V |
|
Driver IC |
ST7565R |
|
Input Data |
Parallel 6800 Series MPU Interface / Parallel 8080 Series MPU Interface / Serial 4-Line SPI Interface |
|
Module Size(W*H*T) |
170*57.6mm |
|
GLASS THICKNESS |
1.1 |
|
CONNECTOR |
PIN |
Display Image
